Product Description
The ProX XC-5PDMX05 is a professional 5-foot DMX cable designed for reliable lighting control signal transmission in stage, DJ, and installation environments. Built for short-range connections, it ensures clean and stable DMX data transfer between controllers, fixtures, and lighting systems.
Engineered with Oxygen-Free Copper (OFC) conductors and a dual twisted-pair design, this cable maintains proper 110-ohm impedance for accurate DMX512 signal performance. Its advanced shielding system—including duofoil and tinned copper braid—helps eliminate interference and preserve signal integrity even in electrically noisy environments.
With gold-plated contacts and all-metal XLR-5 connectors, the XC-5PDMX05 is built for durability, consistent connectivity, and long-term professional use.
Features
- 5 ft 5-pin DMX lighting control cable
- 110-ohm impedance for proper DMX512 transmission
- Dual twisted-pair (4 conductor) design
- Oxygen-Free Copper (OFC) conductors for clean signal transfer
- Duofoil (100%) + braided shield (85%) for interference protection
- Gold-plated contacts for reliable conductivity
- All-metal XLR-5 connectors for durability
- Flexible, long-life construction for touring and stage use
- Designed for professional lighting systems
Specifications
- Cable Length: 5 ft (1.5 m)
- Connector Type: 5-pin XLR (DMX)
- Conductor: 20 AWG x 4 OFC
- Impedance: 110 ohms
- Insulation: Polyethylene
- Shielding:
- Duofoil (100% coverage)
- Tinned copper braid (85% coverage)
- Jacket Material: PVC
- Capacitance (Conductor to Conductor): 12.8 pF/ft @ 1 kHz
- Capacitance (Cond. to Shield): 23 pF/ft @ 1 kHz
- Velocity of Propagation: 66%
- Delay: 1.6 ns/ft
- DC Resistance (Conductor): 24 ohms/1000 ft
- DC Resistance (Shield): 3.4 ohms/1000 ft
- Attenuation: 0.6 dB/100 ft @ 1 MHz
- Max Current: 2.1A per conductor @ 25°C
- Operating Temperature: -30°C to +75°C
