Product Description
The ProX XC-DMX50 is a professional-grade 50-foot DMX cable designed for reliable lighting control and precision data transmission in touring, stage, and production environments. Engineered specifically for DMX512 applications, this high-performance cable connects devices with XLR3 male and female DMX connections while delivering accurate and interference-free signal transfer.
Built with 22AWG oxygen-free copper (OFC) conductors, DuoFoil shielding, and a braided OFC copper compact shield, the XC-DMX50 protects your DMX signal from noise, interference, and data corruption. Its twisted pair data cable construction ensures consistent impedance and dependable communication for professional lighting systems.
Designed to withstand the rigors of live production, the XC-DMX50 features durable all-metal XLR connectors, flexible long-life construction, and ProX’s Complete Coil technology for dependable performance during repeated bending and twisting.
Important: DMX data cables are specifically designed for lighting control and should not be used as audio cables.
Features
- Professional 50 ft. DMX512 lighting control cable
- XLR3 male to XLR3 female configuration
- 22AWG oxygen-free copper conductors
- Twisted pair data cable design for precise DMX transmission
- DuoFoil® shield with 100% coverage
- Braided OFC copper compact shield for noise rejection
- Durable PVC outer jacket
- Gold-plated contacts for reliable connectivity
- Heavy-duty all-metal ProX XLR connectors
- Flexible tour-grade construction
- 110 Ohm characteristic impedance
- Ideal for stage lighting, moving lights, and DMX controllers
- ProX Limited Lifetime Warranty
Applications
- DMX512 lighting systems
- Stage lighting control
- Moving head fixtures
- LED lighting systems
- Touring productions
- Live events and concerts
- Nightclubs and entertainment venues
- Professional AV installations
Specifications
General
- Product Type: DMX Data Cable
- Cable Length: 50 Ft.
- Connector Type:
- XLR3 Male
- XLR3 Female
- Application: DMX Lighting Control
Conductors & Shielding
- Conductors: 22AWG Oxygen-Free Copper (OFC)
- Shielding:
- DuoFoil® (100% Coverage)
- Tinned Copper Braided Shield (85% Coverage)
- Insulation: Polyethylene
- Jacket Material: PVC
Electrical Specifications
- Characteristic Impedance: 110 Ohms
- Conductor to Conductor Capacitance @1KHz: 12.8 pF/ft
- Conductor to Shield Capacitance @1KHz: 23 pF/ft
- Velocity of Propagation: 66%
- Delay: 1.6 ns/ft
- Conductor DC Resistance @20°C: 24 Ohms/1000 ft
- Shield DC Resistance @20°C: 3.4 Ohms/1000 ft
- Attenuation: 0.6 dB/100 ft @1MHz
- Maximum Recommended Current: 2.1 Amps per conductor
Temperature Range
- Operating Temperature: -30°C to +75°C
Packaging
- Master Box Quantity: 5 Cables
