Yamaha MG20 20 Channel Analog Mixer

The Yamaha MG20 is a professional 20-channel analog mixing console designed to deliver high-quality sound, flexible signal routing, and reliable performance for live sound reinforcement, houses of worship, recording applications, events, and installed audio systems. As part of Yamaha's acclaimed MG Series, the MG20 combines studio-grade microphone preamps, intuitive controls, built-in compression, and versatile connectivity in a rugged metal chassis.

Featuring Yamaha's D-PRE discrete Class-A microphone preamps, the MG20 uses an inverted Darlington circuit design to deliver detailed, natural sound with low distortion, powerful low frequencies, and smooth high-frequency reproduction. Custom MG01 operational amplifiers further support clear, high-resolution audio performance across a variety of sound sources.

The MG20 includes 1-knob compressors that make dynamic control simple and accessible. With a single rotary control, users can help manage vocal levels, tighten bass lines, and add punch to instruments without the complexity of traditional external compression equipment. Three-band equalization on mono channels and high-pass filters provide additional control over tone and unwanted low-frequency noise.

Designed for flexible professional mixing, the MG20 offers four group buses, a stereo bus, and four AUX sends, including effects routing. Balanced XLR outputs, multiple microphone and line inputs, stereo RCA inputs, and monitor and headphone connections make it suitable for a wide range of audio setups.

With switchable +48V phantom power, PAD switches on mono inputs, a universal 100–240V power supply, and an included rack-mount kit, the Yamaha MG20 is a versatile solution for musicians, sound engineers, production companies, venues, and professional audio installations.

Features

• 20-channel analog mixing console

• Up to 16 microphone inputs and 20 line inputs

• 12 mono channels and 4 stereo channels

• Yamaha D-PRE discrete Class-A microphone preamps

• Inverted Darlington circuit preamp design

• Custom MG01 operational amplifiers

• 1-knob compressors for convenient dynamic control

• Three-band EQ on mono input channels

• High-pass filters for low-frequency noise control

• PAD switches on mono inputs

• Switchable +48V phantom power

• Four group buses plus one stereo bus

• Four AUX sends, including effects routing

• Balanced XLR stereo outputs

• Monitor outputs and headphone output

• Stereo RCA 2TR inputs for external audio sources

• Two 12-segment LED level meters

• Internal universal power supply

• AC 100–240V operation

• Durable metal chassis

• Rack-mount kit included

Applications

• Live Sound Reinforcement

• Concerts and Live Performances

• Houses of Worship

• Recording Studios

• Band Rehearsals

• Corporate Events

• Schools and Educational Facilities

• Conference Rooms

• Installed Sound Systems

• Theater and Performing Arts

• Event Production

• Professional Audio Rental

Specifications

General

• Manufacturer: Yamaha

• Model: MG20

• Product Type: Analog Mixing Console

• Channel Count: 20

• Mono Inputs: 12

• Stereo Inputs: 4

• Maximum Microphone Inputs: 16

• Maximum Line Inputs: 20

• Chassis: Metal

• Rack Mounting: Supported; rack-mount kit included

Preamps and Audio Processing

• Microphone Preamps: Yamaha D-PRE Discrete Class-A

• Preamp Circuit: Inverted Darlington

• Operational Amplifiers: Custom Yamaha MG01

• Compression: 1-Knob Compressors

• Mono Channel EQ: Three-Band

• High-Pass Filters: Yes

• PAD Switches: Mono Inputs

• Phantom Power: +48V

Buses and Routing

• Stereo Bus: 1

• Group Buses: 4

• AUX Buses/Sends: 4

• Effects Routing: Supported through AUX/FX send

• Master Send Controls: Provided

Inputs and Outputs

• Mono Inputs: Balanced XLR and combo microphone/line connectors

• Stereo Inputs: XLR and phone connectors, depending on channel

• Additional Stereo Inputs: RCA 2TR inputs

• Stereo Outputs: Balanced XLR

• Monitor Outputs: 1

• Headphone Outputs: 1

• AUX Sends: 4

• Group Outputs: 4

• Level Metering: Dual 12-segment LED meters

Audio Performance

• Frequency Response: +0.5 dB / -1.5 dB, 20 Hz–48 kHz

• Total Harmonic Distortion: 0.03% at +14 dBu, 20 Hz–20 kHz

• Total Harmonic Distortion: 0.005% at +24 dBu, 1 kHz

• Equivalent Input Noise: -128 dBu

• Residual Output Noise: -102 dBu

• Crosstalk: -78 dB at 1 kHz

Power Requirements

• Power Supply: Internal universal power supply

• Input Voltage: AC 100–240V

• Frequency: 50/60 Hz

• Power Consumption: 36W

Dimensions and Weight

• Width: 17.5 in / 444.5 mm

• Height: 5.1 in / 129.5 mm

• Depth: 19.7 in / 500.4 mm

• Net Weight: 15.2 lb / 6.9 kg

Environmental Specifications

• Operating Temperature: 0°C to +40°C / 32°F to 104°F
