Product Description
The IRG4PC40UD Ultrafast IGBT Power Transistor is a Generation 4 insulated gate bipolar transistor engineered for high-efficiency, high-frequency switching applications. Optimized for 8–40 kHz operation in hard-switching designs and capable of exceeding 200 kHz in resonant mode, this device delivers superior performance in demanding power electronics systems.
Built using advanced Generation 4 IGBT technology, the IRG4PC40UD provides tighter parameter distribution, reduced switching losses, and higher overall efficiency compared to Generation 3 devices. Housed in an industry-standard TO-247AC package, it is designed as a drop-in replacement for equivalent Generation 3 IR IGBTs, allowing easy upgrades without circuit redesign.
This transistor is ideal for applications such as inverters, motor drives, power supplies, UPS systems, and industrial control equipment where speed, efficiency, and reliability are critical.
Features
-
Ultrafast switching performance optimized for high-frequency operation
-
Hard-switching capability from 8 to 40 kHz
-
Resonant mode operation exceeding 200 kHz
-
Generation 4 IGBT technology for higher efficiency and tighter parameter control
-
Drop-in replacement for equivalent Generation 3 IR IGBTs
-
TO-247AC package for robust mounting and effective thermal management
Specifications
-
Part Number: IRG4PC40UD
-
Transistor Type: IGBT (Insulated Gate Bipolar Transistor)
-
Technology: Generation 4
-
Switching Frequency:
-
8–40 kHz (hard switching)
-
200 kHz (resonant mode)
-
-
Package Type: TO-247AC
-
Mounting Style: Through-hole
-
Applications: Inverters, motor drives, UPS systems, power supplies, industrial electronics
