Product Description
The Nexperia 74LV245D is a high-speed 8-bit non-inverting bus transceiver designed for bidirectional communication between data buses. Featuring 3-state outputs, LVTTL-compatible inputs and outputs, and an operating voltage range of 1V to 5.5V, this CMOS logic IC is ideal for digital systems requiring reliable signal buffering, bus interfacing, and logic-level communication.
Built in a compact SOIC-20 (SOT163) surface-mount package, the 74LV245D provides low power consumption while maintaining fast switching performance. Its direction-control and output-enable inputs make it suitable for microcontroller systems, embedded designs, industrial controls, communication equipment, and electronic repair applications.
Whether you're replacing a failed logic IC or designing a new digital circuit, the 74LV245D offers dependable performance and broad voltage compatibility.
Features
- Genuine Nexperia 74LV245D Bus Transceiver
- 8-bit non-inverting bidirectional bus transceiver
- 3-state outputs for shared bus applications
- LVTTL-compatible input and output levels
- Wide operating voltage: 1V to 5.5V
- Low-power CMOS logic design
- High-speed signal transmission
- SOIC-20 (SOT163) surface-mount package
- Suitable for industrial and commercial applications
- Operating temperature from -40°C to +125°C
Specifications
| Specification | Value |
|---|---|
| Manufacturer | Nexperia |
| Part Number | 74LV245D,118 |
| Function | Bus Transceiver |
| Logic Family | LV |
| Product Type | CMOS Logic IC |
| Number of Circuits | 1 |
| Number of Channels | 8 |
| Polarity | Non-Inverting |
| Output Type | 3-State |
| Input Level | LVTTL |
| Output Level | LVTTL |
| Propagation Delay | 45 ns |
| Low-Level Output Current | 16 mA |
| High-Level Output Current | -16 mA |
| Supply Voltage | 1V to 5.5V |
| Maximum Supply Current | 160 µA |
| Operating Temperature | -40°C to +125°C |
| Mounting Style | Surface Mount (SMD/SMT) |
| Package | SOIC-20 (SOT163) |
| Part Alias | 935063210118 |
Applications
- Microcontroller systems
- Embedded electronics
- Digital communication equipment
- Industrial automation
- Data bus buffering
- Logic level interfacing
- Computer peripherals
- Test and measurement equipment
- Consumer electronics repair
- PCB design and prototyping
