Product Description
Single 18" ACTIVE SUBWOOFER (WOOD ENCLOSURE)
KEY FEATURES
Powerful Class D Amplification
The XPRS2 Series employs Class D Amplification with high output wattage for a powerful and premiere audio experience for performers and listeners alike. The XPRS102 and XPRS122 full-range speakers feature Class D 2000 W amplification, while the XPRS1152S and XPRS1182S subwoofers offer Class D 4000 W amplification.
High Quality, Robust Build
Pioneer DJ’s all-new XPRS2 Series features a sleek all-black, protective plywood cabinet for performance in harsh outdoor and indoor environments. The series models all come with a durable handle to support system portability and handling during setup and take down. The XPRS2 Series also features rubber feet to create separation and shock absorption between surfaces.
Three DSP Modes
Both of the XPRS2 subwoofers contain three different DSP preset modes—Boost, Extended LF, and Normal—to suit different listening environments.
Accurate Audio Performance / Frequency Response
The XPRS1182S relies on an 18” ferrite woofer with a 3” voice coil with long excursion to produce low frequencies with paramount accuracy.
Offers a 40 Hz – 120 Hz frequency response and 130 dB maximum SPL; the subwoofers pack in the performance of a permanent install subwoofer with the compact mobility required by today’s mobile artists, performers and venues.
Main Features
Type |
18 inch active subwoofer |
|---|---|
Amplifier Output |
|
Accessories |
|
Specifications
Power supply |
110 V to 240 V (50 Hz/60 Hz) |
|---|---|
Power consumption |
800 W |
Width |
661 mm |
Depth |
536.5 mm |
Height |
535 mm |
Weight |
32.3 kg |
Frequency Range |
40 – 120 Hz |
System characteristic
DSP modes |
|
|---|---|
DSP presets modes |
|
Maximum Sound Pressure |
130 dB |
Terminals
Inputs |
|
|---|---|
Outputs |
|
Speaker
Driver |
18” ferrite LF cone driver |
|---|---|
Finish |
Black paint, Rubber feet |
Handle |
2 (on both sides) |
Pole socket |
35 mm socket |
Enclosure |
Plywood (TSCA) |
Protection
Amplifier Protection |
|
|---|---|
Driver Protection |
Short circuit protection |
Power unit Protection |
|
