Product Description
The Pioneer DJ XPRS102 is a high-performance 10-inch active 2-way loudspeaker engineered for DJs, live performers, venues, houses of worship, and mobile sound professionals who demand powerful output and exceptional clarity. As part of the XPRS2 Series, this speaker combines 2000W Class D amplification, advanced DSP control, and a rugged plywood enclosure for reliable performance in both indoor and outdoor environments.
Designed for portability and durability, the XPRS102 features a sleek black protective cabinet, integrated metal handle, rubber isolation feet, and multiple rigging points—making it ideal for mobile applications and permanent installations alike.
With a maximum SPL of 129 dB and a frequency response of 50 Hz – 20 kHz, the XPRS102 delivers punchy low-end, detailed mids, and crisp high frequencies for both music playback and speech reproduction.
Key Features
2000W Class D Amplification
-
High-efficiency Class D amplifier
-
2000W peak power output
-
Clean, powerful sound with reduced heat generation
Advanced DSP Control
-
4 Factory Presets: Live, Music, Speech, Monitor
-
16 Custom User DSP Presets (savable and renameable)
-
4-band EQ for precise tuning
-
Subwoofer high-pass frequency selection
Professional Speaker Design
-
10" ferrite low-frequency cone driver
-
2.5" LF voice coil
-
1" exit compression driver
-
1.75" HF voice coil
-
2 kHz crossover frequency
Rugged Plywood Cabinet
-
Durable TSCA plywood enclosure
-
Black protective finish
-
Rubber feet for vibration isolation
-
35 mm pole socket
-
10 x M10 rigging points
-
Integrated metal side handle
Protection Systems
-
Thermal limiting
-
Digital limiter & compressor
-
Short circuit protection
-
AC overcurrent and overvoltage protection
Specifications
General
-
Type: 10" 2-way active loudspeaker
-
Amplifier: Class D
-
Amplifier Output: 2000W Peak
-
Maximum SPL: 129 dB
-
Frequency Range: 50 Hz – 20 kHz
-
Crossover Frequency: 2 kHz
Power
-
Power Supply: 110–240V AC, 50/60 Hz
-
Power Consumption: 800W
Inputs
-
MIC/LINE x1 (Combo XLR/TRS)
-
HI-Z/LINE x1 (Combo XLR/TRS)
-
3.5 mm stereo mini jack x1 (Unbalanced)
Outputs
-
MIX Out (XLR)
Drivers
-
LF Driver: 10" ferrite cone
-
HF Driver: 1.75" compression driver
Physical Dimensions
-
Width: 299 mm (11.77 in)
-
Depth: 310 mm (12.20 in)
-
Height: 520 mm (20.47 in)
-
Weight: 15.5 kg (34.17 lbs)
Construction
-
Enclosure: TSCA Plywood
-
Finish: Black paint
-
Handle: 1 metal side handle
-
Pole Mount: 35 mm socket
-
Rigging Points: 10 x M10
Included Accessories
-
Pioneer DJ XPRS102 (single unit)
-
Power cord
-
Quick start guide
-
Important safety precautions document
