Product Description
The NAC3MPB-1 White PowerCON Chassis Plug Panel Connector is a professional-grade locking AC panel mount connector designed for reliable power input connections in audio, lighting, and stage equipment. Featuring a 3-conductor design with line, neutral, and pre-mating safety ground, this PowerCON chassis connector provides a secure and dependable power interface for professional devices.
Designed as an A-type power-in connector, the NAC3MPB-1 is commonly used on equipment panels, power distribution units, amplifiers, lighting fixtures, and other professional gear requiring a robust locking AC power connection. The quick-lock system ensures the cable connector stays securely attached, preventing accidental disconnection during operation.
Built for durability, this connector features a rugged construction with flat tab terminals for easy wiring and excellent cable retention when paired with compatible PowerCON cable connectors. With a 20A / 250V AC rating, it is capable of handling high-current applications common in professional entertainment environments.
Certified by UL, C-UL, VDE, and SEV, the NAC3MPB-1 meets strict international safety and reliability standards.
Important: PowerCON connectors are designed for equipment power connections and must not be connected or disconnected while under load or live power.
Features
-
Panel mount PowerCON chassis connector
-
A-type power-in (white) AC connector
-
Lockable 3-pole connector (Line, Neutral, Ground)
-
Pre-mating safety ground contact for enhanced protection
-
20A / 250V AC current rating
-
Quick locking system for secure connection
-
Flat tab terminals for easy installation
-
Rugged and reliable construction for professional equipment
-
Certified by UL, C-UL, VDE, and SEV
Specifications
Model: NAC3MPB-1
Connector Type: PowerCON Panel Mount Chassis Connector
Connector Color: White (Power-In)
Number of Contacts: 2 + PE (Line, Neutral, Ground)
Rated Current: 20 A
Rated Voltage: 250 V AC
Termination: Flat Tab Terminals
Mounting Type: Panel Mount
Certifications: UL, C-UL, VDE, SEV
