Product Description
\n
\n
\n55w, 5-inch wooferThe Yorkville YSM5 is the most compact studio monitor in the YSM series, making it perfect for small listening spaces and desktop studios. Unmatched clarity, precise reproduction and surprisingly punchy bottom end response for a monitor in this class, the YSM5 uses a solid ¾-inch MDF cabinet and baffle to reduce rumble and cabinet self-interference. The front facing port design solves the issue of bass coupling with back walls and corners in small environments which can generate false low-frequency information in your mix.
\n
\n
\n
\n
\n
\n
\nFeatures
\n-
\n
- Reproduces source material with near pinpoint accuracy and detail \n
- Contoured MDF baffle engineered to minimize front face reflections \n
- Front facing port design eliminates bass coupling with back walls and corners in imperfect listening environments \n
- Improved phase response provides a wider 'sweet spot' in the listening position \n
- Strategic bracing and ample internal dampening eliminates unwanted low frequency rumble \n
- Biamplified Power Module (40 watts woofer / 15 watts tweeter) \n
- Custom designed soft dome tweeter \n
- High quality low frequency 5-inch woofer \n
- Rock-solid 3/4-inch MDF cabinet construction \n
- XLR and ¼-inch TRS balanced inputs \n
- 4-position high frequency trim control to optimize response for recording space \n
- Front mounted power switch for added convenience \n
Specifications
\n| System Type | \n2-Way | \n
| Active or Passive | \nActive | \n
| Power Rating (Watts) | \n55 | \n
| Biampable | \nSelf Powered | \n
| Biamp Operation Only | \nYes | \n
| Max SPL (dB) | \n105 | \n
| Frequency Response (Hz +/- 3db) | \n52-20,000 | \n
| Crossover Frequency (Hz) | \n3000 | \n
| HF Driver(s) | \n1 inch Neodymium soft-dome tweeter | \n
| HF Power Rating (Watts) | \n15 | \n
| LF Driver(s) | \n5 inch Composite woofer | \n
| LF Power Rating (Watts) | \n40 | \n
| LF Protection | \nThermal / Current Limit | \n
| HF Distortion | \n0.0003 | \n
| LF Distortion | \n0.0002 | \n
| Inputs | \n1 Combi-Jack | \n
| Mixer Controls | \nHF Trim (-2,-1, 0,+1dB) 4-position preset | \n
| Level Controls | \nInput Gain | \n
| Enclosure Materials | \nMDF | \n
| Baffle Material | \nMDF | \n
| Port(s) | \nYes - Front | \n
| Dimensions (DWH xbackW, inches) | \n9.5 x 7.5 x11.5 | \n
| Dimensions (DWH xbackW, cm) | \n24 x 19 x 29 | \n
| Weight (lbs/kg) | \n15 / 6.8 | \n
