Product Description
The RCF EVOX 12 Active Two-Way Array PA System is the most powerful line-source system in its class, delivering exceptional output, clarity, and dynamic performance in a compact and highly portable design. Powered by a 1400W Class-D amplifier, the EVOX 12 provides deep, punchy low frequencies and articulate mid-to-high reproduction, making it ideal for DJs, live performers, corporate events, and professional presentations.
The top array section features eight high-performance 4-inch neodymium full-range transducers with phase plugs, delivering enhanced low-mid response and consistent sound pressure levels with wide and controlled high-frequency dispersion. The 15-inch subwoofer reinforces the system with powerful, tight bass, perfect for live bands, kick drums, and high-energy music playback.
RCF’s advanced EVOX array design offers constant 90° x 30° horizontal and vertical coverage, ensuring uniform sound distribution across the audience. The progressive vertical shaping of the array guarantees clear listening from the front row to the back, while reducing high-frequency beaming commonly found in straight-line arrays.
Despite its high output capabilities, the EVOX 12 remains extremely transport-friendly. The rugged Baltic birch plywood enclosure includes integrated wheels and an extendable handle, allowing for quick setup, breakdown, and effortless mobility. Built-in DSP processing with EQ and protection circuits ensures reliable performance in demanding environments.
Features
-
1400W high-efficiency Class-D amplification
-
Maximum SPL of 130 dB for high-output applications
-
8 × 4" neodymium full-range drivers with phase plugs
-
15" high-power subwoofer with 3.0" voice coil
-
Constant directivity array design for even sound coverage
-
90° x 30° slightly tilted pattern control
-
Advanced onboard DSP with EQ and soft limiter
-
Thermal and RMS protection circuits
-
Compact, road-ready enclosure with wheels and extendable handle
-
Pole-mountable design for fast and easy setup
Specifications
Acoustic Specifications
-
Frequency Response (-3 dB): 40 Hz – 20 kHz
-
Max SPL: 130 dB
-
Horizontal Coverage: 90°
-
Vertical Coverage: 30°
-
Full-Range Drivers: 8 × 4.0", 1.0" voice coil
-
Subwoofer: 15", 3.0" voice coil
Input / Output
-
Input Connectors: XLR / 1/4" Combo (Male)
-
Output Connectors: XLR (Female)
-
Input Sensitivity: -2 dBu / +4 dBu
Processor Section
-
Crossover Frequency: 180 Hz
-
Protections: Thermal, RMS
-
Limiter: Soft limiter
-
Controls: Volume, EQ
Amplifier
-
Total Power: 1400 W Peak
-
High Frequencies: 400 W Peak
-
Low Frequencies: 1000 W Peak
-
-
Total Power: 700 W RMS
-
High Frequencies: 200 W RMS
-
Low Frequencies: 500 W RMS
-
-
Cooling: Convection
-
Power Connection: VDE Connector
Cabinet
-
Material: Baltic birch plywood
-
Handles: 2 side, 1 top
-
Pole Mount / Cap: Yes
-
Color: Black
Physical Specifications
-
Dimensions (H × W × D):
-
87.4" × 16.14" × 22.05"
-
2220 × 410 × 560 mm
-
-
Net Weight: 80.24 lbs (36.4 kg)
