EMINENCE USA THE WIZARD (8 ohm)

Was: $179.99
Now: $139.99
(0) Write a Review
SKU:
122317A-U
Weight:
0.00 LBS
Shipping:
Calculated at Checkout

Product Description

\n \nThe Eminence Wizard guitar speaker will put a spell on your tone. Very articulate, but with a hint of grit. Nice sustain and exceptionally good tight bottom. Classic Rock tones of the 60s and 70s. \n \n
\n
\n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n \n
SPECIFICATION
Nominal Basket Diameter12", 305 mm
Nominal Impedance*8 Ω
Power Rating*
Program PowerN/A
Watts75 W
Resonance89 Hz
Usable Frequency Range80 Hz - 5.3 kHz
Sensitivity*102.8 dB
Magnet Weight56 oz.
Gap Height0.312", 7.9 mm
Voice Coil Diameter1.75", 44 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs)89 Hz
DC Resistance (Re)6.13 Ω
Coil Inductance (Le)0.38m H
Mechanical Q (Qms)11.48
Electromagnetic Q (Qes)0.49
Total Q (Qts)0.47
Compliance Equivalent Volume (Vas)41.5 liters / 1.47 cu.ft.
Peak Diaphragm Displacement Volume (Vd)41.6 cc
Mechanical Compliance of Suspension (Cms)0.11 mm/N
BL Product (BL)14.4 T-M
Diaphragm Mass Inc. Airload (MMs)30 grams
Efficiency Bandwidth Product (EBP)181
Maximum Linear Excursion (Xmax)0.8 mm
Surface Area of Cone (Sd)519.5 cm2
Maximum Mechanical Limit (Xlim)N/A
MOUNTING INFORMATION
Recommended Enclosure Volume
SealedAcceptable
VentedN/a
Driver Volume Displaced0.079 cu.ft. / 2.25 liters
Overall Diameter12.03", 305.6 mm
Baffle Hole Diameter11.07", 281.2 mm
Front Sealing GasketYes
Rear Sealing GasketYes
Mounting Holes Diameter0.25", 6.4mm
Mounting Holes B.C.D.11.59", 294.4mm
Depth5.2", 132.1 mm
Net Weight11.1 lbs, 5.03 kg
Shipping Weight12.5 lbs, 5.67 kgs
MATERIALS OF CONSTRUCTION
Coil ConstructionCopper voice coil
Coil FormerNomex former
Magnet CompositionFerrite magnet
Core DetailsNon-vented core
Basket MaterialsPressed steel basket
Cone CompositionPaper cone
Cone Edge CompositionPaper cone edge
Dust Cap CompositionZurette dust cap
