Product Description
The AUVI Prod FP20Q is a high-performance 20,000 watt 4-channel power amplifier designed for professional subwoofer systems, large PA setups, touring rigs, and event production.
Delivering up to 5,000 watts per channel at 2Ω, the FP20Q provides massive output power with exceptional clarity, stability, and reliability. Built on advanced Class TD technology, this amplifier offers high efficiency, low distortion, and superior dynamic response — ideal for DJs, concert production, churches, and rental companies.
Operating at 127V / 30A, the FP20Q is engineered for demanding professional environments.
Key Features
- 20,000 Watts Total Output Power
- 4-Channel Professional Power Amplifier
- Class TD High-Efficiency Design
- Ideal for subwoofer systems and full-range PA setups
- Tour-grade protection systems
- Heavy-duty build for professional applications
Power Output (RMS)
- 8Ω Stereo: 2500W × 4
- 4Ω Stereo: 4200W × 4
- 2Ω Stereo: 5000W × 4
- 8Ω Bridged: 8400W × 2
- 4Ω Bridged: 10,000W × 2
Performance Specifications
- Frequency Response: 6.8 Hz – 34 kHz
- THD: <0.01% (6.8 Hz – 20 kHz @ 1W)
- Signal-to-Noise Ratio: >112 dBA
- Channel Separation: >70 dB @ 1 kHz
- Damping Factor: >1000
- Selectable Gain: 23 / 26 / 29 / 32 / 35 / 38 / 41 / 44 dB
- Input Impedance: 20 kOhm
Connectivity
- Inputs: 3-Pin XLR (Electronically Balanced)
- Outputs: Speakon
Protection System (Tour Class)
- ACL (Active Clip Limiter)
- IGM Protection
- AutoRamp
- Short Circuit Protection
- DC Voltage Protection
- Turn-On/Off Transient Protection
- Current Inrush Protection
- Sub/Ultrasonic Input Protection
Technical Details
- Operating Voltage: 127V
- Current Draw: 30A
- Net Weight: 41.88 lbs (19 kg)
- Model: AVP-FP20Q
Ideal Applications
- Professional DJ systems
- Large subwoofer arrays
- Concert sound reinforcement
- Churches & houses of worship
- Touring production
- Rental companies
