Product Description
The 47µF 25V Aluminum Electrolytic Capacitor (ESW Series, Radial Leaded) is a compact and reliable component designed for general-purpose electronic applications. With a capacitance of 47µF and a 25V DC rating, this capacitor is ideal for filtering, coupling, decoupling, and energy storage in a wide range of circuits.
Engineered for durability, this capacitor features a 105°C temperature rating and a 3000-hour lifespan, ensuring stable performance in demanding environments. Its radial leaded design with 2mm lead spacing allows for easy through-hole PCB installation, while the compact 5mm diameter and 11mm length make it suitable for space-constrained designs.
With low leakage current and consistent electrical characteristics, this ESW series capacitor provides dependable performance in consumer electronics, power supplies, and audio equipment.
Features
- Capacitance: 47µF
- Voltage Rating: 25V DC
- 105°C temperature rating for reliable operation
- 3000-hour lifespan for long-term use
- Compact size: 5mm diameter × 11mm length
- Radial leaded design with 2mm spacing
- Low leakage current for stable performance
- General-purpose use for filtering and smoothing
- ±20% tolerance
Specifications
Electrical Characteristics
- Capacitance: 47µF
- Voltage Rating (DC): 25V
- Tolerance: ±20%
- Dissipation Factor (DF): 14%
- Leakage Current: 12 µA
- Ripple Current: 180 mA
Thermal & Lifetime
- Operating Temperature: -40°C to +105°C
- Life Rating: 3000 hours
Physical
- Diameter: 5 mm
- Length: 11 mm
- Lead Spacing: 2 mm
- Lead Style: Straight
- Mounting / Termination: Radial
General
- Series: ESW
- Product Type: Aluminum Electrolytic Capacitor
