Product Description
The AlphaTheta XDJ-AZ is a 4-channel professional all-in-one DJ system built for performers who demand club-standard workflow, cutting-edge connectivity, and uncompromising sound quality. Designed with the same layout philosophy as Pioneer DJ’s flagship CDJ-3000 players and DJM-A9 mixer, the XDJ-AZ delivers a familiar, confidence-inspiring experience for DJs transitioning from home, studio, or mobile setups to professional stages.
At the heart of the system is a 10.1" capacitive touchscreen that dramatically enhances browsing, track selection, and performance control. DJs can view up to 13 tracks simultaneously, preview music before loading, and access up to four playlists instantly using Playlist Bank. Advanced features like Touch Preview and Touch Cue help ensure smooth, precise transitions during live performances.
With StreamingDirectPlay, the XDJ-AZ connects directly to Apple Music and Beatport, allowing you to stream tracks and playlists without a laptop. Built-in analysis automatically prepares waveforms, BPM, and beat grids, giving you full creative control even when playing streamed content. rekordbox CloudDirectPlay keeps playlists and performance data synced across devices for a seamless workflow.
Integrated SonicLink wireless technology enables ultra-low-latency monitoring when paired with AlphaTheta HDJ-F10 headphones. With response times up to 20× faster than Bluetooth, SonicLink provides cable-free monitoring that stays perfectly in sync with your mix. Combined with pristine audio performance and professional I/O, the XDJ-AZ is a powerful, self-contained DJ solution for clubs, studios, and high-end mobile rigs.
Features
-
4-channel standalone DJ system with club-standard layout
-
Inspired by CDJ-3000 players and DJM-A9 mixer
-
10.1" capacitive touchscreen with advanced track browsing
-
StreamingDirectPlay support for Apple Music and Beatport
-
rekordbox CloudDirectPlay for synced playlists and performance data
-
Full-size jog wheels for precise scratching and pitch control
-
Integrated SonicLink ultra-low-latency wireless headphone monitoring
-
PRO DJ LINK support for synced beat and on-air data
-
Dedicated Beat FX buttons for expressive transitions and effects
-
Wi-Fi and Bluetooth connectivity for flexible performance setups
Specifications
General
-
Power Requirements: AC 110–240V, 50Hz / 60Hz
-
Power Consumption: 60W
-
Power Consumption (Off): 0.3W
-
Weight: 29.8 lb (13.5 kg)
-
Dimensions (W x D x H): 35.24" x 19.85" x 5.25"
-
Operating Temperature: 41°F – 95°F
-
Operating Humidity: 5% – 85% (non-condensing)
Audio Section
-
Sampling Rate: 44.1 kHz
-
Master D/A Converter: 32-bit
-
Other A/D & D/A Converters: 24-bit
Frequency Response
-
USB / LINE / MIC 1 / MIC 2: 20 Hz – 20 kHz
Signal-to-Noise Ratio (A-Weighted)
-
USB: 115 dB
-
LINE: 96 dB
-
PHONO: 85 dB
-
MIC: 79 dB
Total Harmonic Distortion
-
USB: 0.0018%
-
LINE: 0.005%
Inputs
-
LINE / PHONO: RCA (2 sets)
-
MIC: XLR & 1/4" TRS combo (2 sets)
Outputs
-
MASTER 1: XLR
-
MASTER 2: RCA
-
BOOTH: 1/4" TRS
-
PHONES: 1/4" TRS and 3.5mm stereo
USB & Networking
-
USB Type-A: 2 ports (5V / 1A max)
-
USB Type-C: 1 port
-
LAN (PRO DJ LINK): 100BASE-TX
-
Wireless LAN: IEEE 802.11 a/b/g/n/ac (2.4 GHz / 5 GHz)
Bluetooth
-
Version: Bluetooth 5.3
-
Codecs: SBC, AAC
-
Range: Approx. 65 ft (unobstructed)
SonicLink
-
Frequency Band: 2.4 GHz
-
Range: Approx. 16 ft (unobstructed)
